Inicio > Productos > Generador-50Hz
KP-C Series - YUCHAI Motor
El generador de la serie KEYPOWER Yuchai está propulsado por un motor diesel Yuchai que cubre un amplio rango de potencia de 50kva hasta 3000kva, Yuchai también es el socio de MTU en China que fabrica
none
  • Detail
  • Order


DIESEL GENERATOR SPECIFICATIONS
1. Powered by reliable engines
2. Branded alternator
3. Open type, silent type or super silent type generator
4. ISO, CE certified

GENERATOR SPECS:
Rated output: 2 to 2,000kW/2 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz

ENGINE:
Brands: Cummins, Perkins, Lovol, Deutz, Doosan, Mitsubishi, Kubota, Yanmar or other reliable Chinese engines such as Fawde and Laidong.
Cooling method: closed water-cooled or air-cooled
Starting method: electric start or recoil start
Rated speed: 1,500/1,800/3,000/3,600rpm
Noise level: 56 to 75dB, 7 meters away

ALTERNATOR:
Brands: Stamford, Leroy Somer, Mecc Alte and Keypower brushless alternator
Rated output: 8 to 2,000kW/10 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Phase: 3-phase, 4-wire or 1-phase, 2-wire
Connection: y or other type connection
Rated speed: 1,500/1,800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: AVR automatic
1.0% voltage regulation in static conditions (maximum)
Protection class: IP23
Control panel: Deepsea, ComAp, Keypower

THE PANEL IS PROVIDED WITH:
Standard engine instrumentation
Voltmeter with selector switch
Ammeter with selector switch
Frequency meter
Current transformers
MCB of suitable rating with overload and short-circuit protection
Optional with AMF control panel or with ATS (automatic transfer switch)

APPLICATIONS:
With advanced reasonable structure, high efficiency, low vibration and noise, smooth running, high reliability, easy handling, KEYPOWER generators are widely used in national defense, telecommunications, construction site, commercial buildings, industrial and mining sites, oil fields, roads, ports, villas, banks, hospitals etc.

ANY QUESTION, PLEASE CONTACT US DIRECTLY.



Genset Model400/230V   3Phase 4 Wires  50Hz COSφ=0.8Parameters   of  CUMMINS  Diesel Engine  1500rpm
Standby PowerPrime   PowerMaximum   Current            (A)Engine   ModelCyl.

Displacement

 (L)

Comsumption

 (Full Load)

(L/h)

KVAKWKVAKW
KP-Y20P-122222020554D24G2/A42.456.2
KP-Y20P2217.62016324D24G4/A42.455
KP-Y25P27.5222520404D24G2/A42.456.2
KP-Y30P30243024434D24TG2/A42.457.2
KP-Y38P413337.530594D24TG0/A42.459.3
KP-Y50P5544504079YC4D85Z-D20-mec44.2114.2
KP-Y50P5544504079YC4D85Z-D2044.2114.2
KP-Y56P62.550564590YC4D85Z-D20-mec44.2114.2
KP-Y56P62.550564590YC4D85Z-D2044.2114.2
KP-Y60P6652604895YC4D90Z-D2144.2115.5
KP-Y73P806472.558115YC4A100Z-D2044.8416.4
KP-Y85P92.5748568134YC4A140L-D2044.8422
KP-Y100P1108810080159YC4A140L-D2044.8422
KP-Y113P12510011390180YC6B155L-D2166.8723
KP-Y125P137.5110120100198YC6B180L-D2066.8726
KP-Y150P165132150120238YC6B205L-D2066.8730
KP-Y175P192.5154175140278YC6A230L-D2067.2637
KP-Y188P207165188150299YC6A245L-D2167.2639
KP-Y200P220176200160318YC6A275-D3067.2643
KP-Y225P250200225180361YC6MK285L-D20610.3445
KP-Y250P275220250200397YC6MK350L-D20610.3455
KP-Y313P344275313250497YC6MK420L-D20610.3465
KP-Y350P385308350280556YC6MJ480L-D20611.7375
KP-Y375P412.5330375300595YC6K500-D31612.1678
KP-Y400P440352400320635YC6K520-D30612.1682
KP-Y438P481385438350694YC6K570-D30612.9490
KP-Y450P500400450360722YC6T600L-D22616.3594
KP-Y500P550440500400794YC6T660L-D20616.35103
KP-Y563P625500563450902YC6TD780L-D20619.6122
KP-Y625P688550625500993YC6TD840L-D20619.6131
KP-Y688P7506006885501083YC6TD900-D31619.6142
KP-Y750P8256607503001191YC6TD1000-D30619.6157
KP-Y810P8907128106481285YC6C1070L-D20639.58166
KP-Y913P10008009137301443YC6C1220-D31639.58189
KP-Y1000P110088010008001588YC6C1320-D31639.58204
KP-Y1125P1250100011259001804YC6C1520-D31639.58235
KP-Y1250P13751100125010001985YC12VC1680-D311279.17256
KP-Y1375P15001200137511002165YC12VC2070-D311279.17315
KP-Y1500P16501320155012002382YC12VC2070-D311279.17315
KP-Y1650P17701416165013202555YC12VC2270-D311279.17347
KP-Y1900P20001600190015202887YC12VC2510-D311279.17384
KP-Y2000P22001760200016003176YC12VC2700-D311279.17412
KP-Y2200P23601888220017603406YC16VC3000-D3116105.56460
KP-Y2500P27002160250020003897YC16VC3300-D3116105.56505
KP-Y2750P29162333275022004209YC16VC3600-D3116105.56551
