KEYPOWER UK/US Cummins engine powered Generators 5
KEYPOWER Cummins G-Drive series generator is powered by Cummins G-Drive engine which is with more compact design and more eco-friendly, it also features cutting edge technologies such as ECU which fur
  • Detail
  • Order




ALTERNATOR:
Brands: Stamford, Leroy Somer, Mecc Alte and Keypower brushless alternator
Rated output: 8 to 2,000kW/10 to 2,500kVA
Rated voltage: L-N 110 to 277V, L-L 220 to 480V
Rated frequency: 50/60Hz
Phase: 3-phase, 4-wire or 1-phase, 2-wire
Connection: y or other type connection
Rated speed: 1,500/1,800rpm
Excitation: harmonic excitation or phase compound or brushless
Voltage regulation: AVR automatic
1.0% voltage regulation in static conditions (maximum)
Protection class: IP23
Control panel: Deepsea, ComAp, Keypower

THE PANEL IS PROVIDED WITH:
Standard engine instrumentation
Voltmeter with selector switch
Ammeter with selector switch
Frequency meter
Current transformers
MCB of suitable rating with overload and short-circuit protection
Optional with AMF control panel or with ATS (automatic transfer switch)

APPLICATIONS:
With advanced reasonable structure, high efficiency, low vibration and noise, smooth running, high reliability, easy handling, KEYPOWER generators are widely used in national defense, telecommunications, construction site, commercial buildings, industrial and mining sites, oil fields, roads, ports, villas, banks, hospitals etc.

ANY QUESTION, PLEASE CONTACT US DIRECTLY.

Genset Model400/230V 3Phase 4 Wires  50Hz COSφ=0.8Parameters of  CUMMINS  Diesel Engine  1500rpm
Standby PowerPrime Power

Maximum Current

(A)

Engine ModelCyl.Displacement(L)

Comsumption

(Full Load)

(L/h)

KVAKWKVAKW
KP550550440500400794 QSX15-G86L15103
KP7127125706505201028 VTA28-G512V28145
KP8258256607506001191 VTA28-G612V28180
KP8258256607506001191 QSK23-G26L23151
KP8808807048006401270 QSK23-G36L23161
KP102510258289407521480 QST30-G312V30.48184
KP1100110088010008001588 QST30-G412V30.48202
KP182518251460165013202634 QSK50-G716V50.3349
KP206320631650187515002978 QSK60-G316V60.2371
KP225022501800200016003248 QSK60-G416V60.2394
KP250025002000200016003609 QSK60-G1316V60.2399
